Attachments Removal and Installation of Bucket Link ・ Stop the machine on a level location with good footing. ・ Be sure to stop the engine before beginning work. ・ When working together with others, always be sure to exchange signals and pay adequate Caution attention to safety. ・ Always wear protective devices (protective eyewear and safety shoes, etc.) when working with a hammer.
Items to prepare • 2 wrenches (30 mm) • Hammer • Striking rod • Grease • Rag • Cleaning fluid [1] Remove the bucket. (For details, see "Removal and Installation of Bucket".)
E
IN
TE
RN
[2] Place the bucket link (1) parallel to the ground.
AL
1. Removal of Bucket Link
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
[3] Use 2 wrenches (30 mm) to remove the double nuts (2), and then pull out the bolts (3) and (4).
383
1
Bucket link
2
Nut
3
Bolt
4
Bolt
RSM-13-15-001E 3
