Tank Tank
SH200-5
Tank Removal and Installation of Hydraulic Oil Tank ・ Keep away from fire. ・ Bleed off the pressure in the hydraulic oil tank before beginning work. Warning ・ The temperature of the hydraulic oil is high immediately after stopping the engine. Wait until the hydraulic oil temperature has decreased (to 40 ℃ or less) before beginning work. ・ Be sure to stop the engine before beginning work. Caution ・ Be sure to inspect the nylon sling and other lifting equipment before beginning work. ・ Do not go under the suspended load.
Items to prepare • Wrenches (7 mm, 19 mm, 22 mm, 27 mm, 36 mm) • Eyebolts (M12) x 2 • Shackle (with the required lifting capacity) x 2 • Wire rope (with the required breaking load) • Crane (with the required lifting capacity)
AL
• Marking pen • Caps • Plugs
• Cleaning fluid • Wood planks, etc.
IN
1. Removal of Hydraulic Oil Tank
TE
RN
• Waste oil can • Rag
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
[1] Drain the oil from the hydraulic oil tank. (For details, see "Drauning Oil from Hydraulic Oil Tank".) [2] Use a wrench (19 mm) to remove the 6 bolts (1), and then remove the under cover (2).
365
1
Bolt
2
Under cover
RSM-13-14-001E 1
