Other Valves Other Valves
SH200-5
Other Valves Removal and Installation of 5 Stack Solenoid Warning ・ Be sure to release hydraulic pressure before beginning work.
Caution ・ Be sure to stop the engine before beginning work.
Items to prepare • Wrenches (13 mm, 17 mm, 19 mm, 22 mm) • Marking pen • Caps • Plugs • Rag • Cleaning fluid
IN
TE
RN
[1] Attach the specialty adapter (1) to the area where the air breather was removed, and set the vacuum pump (2). Create negative pressure in the hydraulic oil tank using the vacuum pump.
AL
1. Removal of 5 Stack Solenoid Valve
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
[2] Use a wrench (13 mm) to remove the 2 cover bolts (3), and then remove the cover (4).
335
1
Specialty adapter
2
Vacuum pump
3
Bolt
4
Cover
RSM-13-12-001E 1
