Remote Control Valve Removal and Installation of Travel Remote Control Valve Warning ・ Be sure to release hydraulic pressure before beginning work.
Caution ・ Be sure to stop the engine before beginning work.
Items to prepare • Wrenches (17 mm, 19 mm) • Hexagon wrench (8 mm) • Phillips screwdriver • Marking pen • Caps • Plugs • Rag • Cleaning fluid
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
RN
[1] Remove the 3 screws (1) on the cover (2) and remove the cover.
AL
1. Removal of Travel Remote Control Valve
[2] Remove the floor mat (3).
1
279
Screw
2
Cover
3
Floor mat
RSM-13-10-001E 23
