Remote Control Valve Remote Control Valve
SH200-5
Remote Control Valve Removal and Installation of Operation Remote Control Valve Warning ・ Be sure to release hydraulic pressure before beginning work.
Caution ・ Be sure to stop the engine before beginning work.
Items to prepare • Wrenches (19 mm, 22 mm) • Box wrench (10 mm) • Hexagon wrench (5 mm) • Phillips screwdriver • Marking pen • Caps • Plugs
AL
• Rag • Cleaning fluid
1. Removal of Operation Remote Control Valve (Left Side)
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
RN
[1] Roll up the boot (1) of the control lever and use the Phillips screwdriver or box wrench (10 mm) to remove the 2 bolts (2) of the console top cover.
[2] Use the Phillips screwdriver to remove the 2 screws (3), and then remove the handle of the tilt lever (4).
257
1
Boot
2
Bolt
3
Screw
4
Tilt lever
RSM-13-10-001E 1
