Hydraulic Pump Hydraulic Pump
SH200-5
Hydraulic Pump Removal and Installation of Hydraulic Pump Warning ・ Be sure to release hydraulic pressure before beginning work. ・ Be sure to stop the engine before beginning work. Caution ・ Be sure to inspect the wire rope and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare • Wrenches (13 mm, 14 mm, 17 mm, 19 mm, 22 mm, 30 mm, 36 mm) • Hexagon wrenches (8 mm, 10 mm) • Nylon sling (with the required breaking load) • Crane (with the required lifting capacity) • Marking pen • Caps • Plugs • Rag
AL
• Cleaning fluid • Wood planks, etc.
RN
1. Removal of Hydraulic Pump
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[1] Use a wrench (19 mm) to remove the 6 bolts (1), and then remove the under cover (2).
[2] Remove the engine hood. For procedure, see "Removal and Installation of Engine Hood". [3] Use a wrench (19 mm) to remove the 4 bolts (3) from the top cover.
1
225
Bolt
2
Under cover
3
Bolt
RSM-13-09-001E 1
