Center Joint Center Joint
SH200-5
Center Joint Removal and Installation of Center Joint ・ Be sure to stop the engine before beginning work. Caution ・ Be sure to inspect the wire rope and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare • Wrenches (17 mm, 19 mm, 27 mm, 36 mm) • Hexagon wrench (5 mm) • Box wrench (19 mm) • Specialty adapter for vacuum pump connection • Vacuum pump (vacuum pump power supply) • Extension cable • Marking pen • Caps • Plugs
AL
• Wire rope (with the required breaking load) • Crane (with the required lifting capacity) • Wood planks, etc.
RN
• Rag • Cleaning fluid
TE
1. Removal of Center Joint
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[1] Use a hexagon wrench (5 mm) to remove the 4 bolts (1), and then remove the air breather (2) on the hydraulic oil tank.
[2] Attach the specialty adapter (3) to the area where the air breather was removed, and set the vacuum pump (4). Create negative pressure in the hydraulic oil tank using the vacuum pump.
1
217
Bolt
2
Air breather
3
Specialty adapter
4
Vacuum pump
RSM-13-07-001E 1
