Upper Roller Removal and Installation of Upper Roller ・ When loosening the check valve, loosen it a little at a time and stop when any grease appears. (The pressure inside the cylinder is very high, so there is the danger of grease Warning being expelled and the plug flying off if the check valve is loosened too much.) The check valve adjustment procedure should not be done in front of the check valve. Caution ・ Be sure to stop the engine before beginning work.
Items to prepare • Box wrenches (19 mm, 30 mm) • Jack (That meets the lifting weight.) • Rag • Cleaning fluid • Wood planks, etc. [1] Use a box wrench (19 mm) to loosen the grease cylinder check valve (1), then loosen the shoe tension.
E
IN
TE
RN
• Grease drains out, so provide rag (2) close to the drain port. Do not loosen the check valve all at once. Loosen it slowly while monitoring the grease output and shoe loosening.
AL
1. Removal of Upper Roller
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
[2] Use a jack (3) to lift the top of the shoe, and then insert wood planks (4) to separate the shoe (5) and upper roller (6) by about 10 mm.
98
1
Check valve
2
Rag
3
Jack
4
Wood plank
5
Shoe
6
Upper roller
RSM-13-04-001E 1
