Take-up Roller Take-up Roller
SH200-5
Take-up Roller Removal and Installation of Take-up Roller ・ When loosening the grease cylinder check valve, loosen it a little at a time. ・ The pressure inside the cylinder is very high, so there is a danger of grease being expelled and the plug flying off. The check valve adjustment procedure should not be done in front of the check valve. Warning ・ Do not get under the machine when the main unit is jacked up. ・ Make sure to place the main unit on wood planks or the like to prevent falling. ・ Align the shoe assembly feed location and stop the engine except when working.
Items to prepare • Wrench (24 mm) • Hammer • Lifting equipment • Loctite #262 • Striking jig
AL
• Crane • Crowbar • Wood planks, etc. • Rag
RN
1. Removal of Take-up Roller
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
[1] Remove the shoe assembly. See the "Removal and Installation of Shoe Assembly" procemdure. [2] Use a crowbar (3) to pull off the take-up roller (1) and recoil spring assembly from the side frame (2).
83
1
Take-up roller
2
Side frame
3
Crowbar
RSM-13-03-001E 1
