Travel Unit
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE R
NA L
10)Holder attachment Engage the internal teeth of the holder (17) with the teeth of sun gear C (15) and attach sun gear C.
11)Planetary gear attachment Attach the thrust plates (18) to the planetary gears (21). Next, attach the needle bearings (20) to the planetary gears. Finally, after attaching the inner races (19), join the holder (17) trunnion sections (3 locations) with the internal diameter sections of the inner races to attach the planetary gears to the holder. Cautions: a. When attaching the thrust plates to the planetary gears, make sure the shear droop on the thrust plates created by the press is facing the holder side. b. When finally attaching the planetary gears to the holder, attach so that the internal teeth of the housing (4) engage with the planetary gear teeth. c. Be careful with the attachment directions of the planetary gears.
RSM-13-02-001E
*1
Make the shear droop side face the holder B (17) side.
*2
Thrust plate (18) attachment direction
50 44
