6) Holder attachment Secure the flange (1-1) and stand the pins (31) straight up on the flange in 4 locations. Use grease to attach the shim selected in 5) to the holder (6), and press fit the shim with it on the holder in alignment with the pin holes. Mount the washers (7) on the holder, apply Loctite to the threaded sections, and tighten the bolts (8) to the specified torque. Cautions: a. Check that the pins (31) have not fallen. b. The loosening stop spikes should be attached to the washers. Put the spikes on the holder seating surface side to mount them. c. Thoroughly clean the bolt threaded sections and apply Loctite after degreasing. d. Also thoroughly clean the internal areas of the screw holes of the flange, and thoroughly degrease them.
NA L
Travel Unit
47
*
Be careful to attach the washers (7) in the correct direction. Attach them in the direction shown in the diagram above.
*1
Holder side
*2
Bolt seating surface side
