Travel Unit
IN E
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
4) Secure the cylinder block (1-4-1) on the manual press platform with the sliding surface facing up, remove the snap ring (1-4-5), press the collar (1-4-8) with the removal jig to make the spring (1-4-7) bend, and use snap ring pliers to remove the snap ring. Caution: When removing the snap ring, observe the following precaution. a. The snap ring is stiff and may come off from the snap ring pliers when the snap ring is being removed, which could cause injury. When removing the snap ring, make sure to use a disassembly jig and check that the nails of the snap ring pliers are in the snap ring hole before removal. 5) Remove the collar (1-4-8), spring (1-47), and spring seat (1-4-6) from the cylinder block (1-4-1).
TE R
NA L
3) Remove the retainer holder (1-4-4) from the cylinder block (1-4-1) and remove the pins (1-4-9) from the cylinder block.
31
RSM-13-02-001E 25
