Travel Unit
TE R
NA L
[13] Use a box wrench (24 mm) to remove all 30 bolts (18).
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[14] Remove the travel motor (16).
11
16
Travel motor
18
Bolt
RSM-13-02-001E 5
