Travel Unit
TE R
NA L
[7] Place a striking jig (9) against the master pin (7) and hit it with a hammer (8) to push the master pin out.
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[8] Open the shoe (2) to the rear.
[9] Use a wrench (19 mm) to remove the 4 bolts (10), and then remove the cover (11).
9
2
Shoe
7
Master pin
8
Hammer
9
Striking jig
10
Bolt
11
Cover
RSM-13-02-001E 3
