Route Management Manual Building Routes
Building Routes All newly programmed routes must be “built” before the truck is able to follow those routes. Building compiles and stores all of the camera images and Behaviors that have been trained. The automated truck uses this information to follow a route. You have the option to build any route immediately after training, or continue to train multiple routes and build them all at once. While the build is in process, you may drive the truck manually. On the “Training and Service” screen select “2. Build all routes”. The “Build Progress” screen is displayed, as shown in Figure 49. Figure 49. “Build Progress” screen, displayed on the GOI.
NOTE: Do not turn off the truck while it is building routes. When route building is complete, the automatic mode horn will sound and the “Build Complete” screen is displayed, as shown in Figure 50. Press the Option Key below “OK”.
88
1134254B, Revised: 30 Sep 2016
