Route Management Manual
Figure 46. “Enter Ramp” Screen
NOTE: Ramp grade is defined as vertical rise divided by horizontal length, multiplied by 100, and stated as a percent. Vertical Rise
Horizontal Length
5. Drive the truck straight on the ramp until all wheels are on level ground, then stop. Select “1. Exit ramp”. Continue training the route.
Minimize the distance traveled once all wheels are on level ground. The truck’s sensor ranges are adjusted when Ramp features are programmed. Extended travel on level ground with a Ramp feature engaged may result in the sensors being unable to identify an obstruction. NOTE: Behaviors may not be programmed while programming a Ramp Zone.
1134254B, Revised: 30 Sep 2016
83
Training the Truck
Training Routes
