Route Management Manual Training Routes
Start Training a New Route Using the facility route map, select the start and end stations for the route you will be training. Note the locations of all intermediate stations and behaviors along the route that will be trained. Manually position and orient the truck at the Station you wish to begin your route. Apply a Station Marker in line with the truck feature you have selected (see "Station Markers" on page 56). 1. From the “Training and Service” screen, select “1. Train New Route”. The “Train Route Preparation” screen is displayed, as shown in Figure 37. Figure 37. ”Train Route Preparation” screen, displayed on the GOI.
2. Enter the Station ID for your current location in the “From Station:” field; press the Enter Key. Enter the Station ID of the location you intend to finish training the route in the “To Station:” field; press the Enter Key. 3. The “Training” screen is displayed, as shown in Figure 38. Manually operate the truck along the planned route, adding Behaviors (including Drop-Offs), Stations, and Zones (for example: Slow Travel, Intersections, Ramps, or Uneven Floor Areas), where appropriate, as described in the following sections. Do not allow the truck’s Stop Field to cross over any object in the area of the truck.
