Route Management Manual
•
Enter Key: Accepts the current selection and advances you to the next screen.
•
Backspace Key: Removes the last character entered when entering characters in a field.
•
Screen: Displays information regarding the automated truck system.
•
Start Button: Starts automatic movement of the automated truck when prompted.
See your Operator Manual’s “Automated Truck Operation” section for the correct “Start-Up Procedure”. The “Main Menu” screen is displayed, as shown in Figure 33. Select “4. Log In” and press the Enter Key. Figure 33. “Main Menu” screen, displayed on the GOI.
The “Type in your PIN” screen is displayed, as shown in Figure 34. Enter your 4-digit PIN in the appropriate field and press the Enter Key. NOTE: The factory default PIN is 1234. Changing to a new PIN is highly recommended. Make sure to record the electronic key code and keep it in a secure location. Only supervisors or trained route manager should have the password. Refer to the Maintenance Manual for instructions on how to change your password. Your local authorized
1134254B, Revised: 30 Sep 2016
65
Training the Truck
Accessing Training and Service Features
