Accessing Training and Service Features The Graphical Operator Interface (GOI) is mounted on the arch crossbar. The GOI interface is where an operator interacts with the automated truck to access features such as automated system information; align the steering; enter an automated system log-in PIN; access service screens; and train and enter routes. NOTE: The GOI screen is not touch-sensitive. Figure 32. Graphical Operator Interface (GOI) Controls E-Stop Button
Screen
Fully Manual Mode
Arrow Keys
Manual/ Automatic Mode
Option Keys
Keyed Mode Selector Switch
Back Key
Backspace Key
Cancel Key
Enter Key
Number Keys
Start Button
•
Option Keys: Allow an operator to make a selection when prompted with a list of options from the GOI screen.
•
Arrow Keys: Allow an operator to scroll and page up/down through lists and menus.
•
Back Key: Returns to the previous screen.
• •
Number Keys: Allow an operator to enter numbers into the GOI screen. Cancel Key: Cancels the recently made selection.
•
Emergency Stop (E-Stop) Button: Used to stop truck motion.
•
Keyed Mode Selector Switch: Choose Fully Manual or Manual/Automatic Mode to permit different features of the automated truck.
