Route Management Manual The Truck
The Truck Truck characteristics must be understood in order to develop the best route for your application.
Dimensional Characteristics The truck’s dimensional characteristics [truck width, fork length, cart size, load width, number of carts], including the Light Curtain Module’s and Obstruction Sensor’s dimensional characteristics, must be understood to determine the best routes for the truck. Figure 2. Truck Specific Dimensions
C
A B Table 1.
Dimensional Characteristics A Truck Length inch (mm)
B Truck Length inch (mm)
C Truck Width inch (mm)
Model 3010 with 36” Forks
67.5 (1715)
103.1 (2619)
35.5 (902)
Model 3010 with 42” Forks
67.5 (1715)
109.1 (2771)
35.5 (902)
Model 3010 with 48” Forks
67.5 (1715)
115.1 (2824)
35.5 (902)
Model 3010 with 60” Forks
67.5 (1715)
127.1 (3228)
35.5 (902)
Model 3010 with 84” Forks
67.5 (1715)
151.3 (3843)
35.5 (902)
Model 3010 with 93” Forks
67.5 (1715)
160.3 (4072)
35.5 (902)
Model 3010 with 96” Forks
67.5 (1715)
163.3 (4148)
35.5 (902)
Model 3020
66.1 (1679)
–
35.5 (902)
Truck Configuration
NOTE: Subtract 6 in. (152 mm) when 17.25 in. (438 mm) for Model 3010 or 15.8 in. (401 mm) for Model 3020 operator compartment is used.
