Route Management Manual To Use the Training Tool Figure 67. 3010 (Raymond Courier Center Rider) Recommended Laser Training Tool Locations Minimum Aisle Width with Hazard Zones and +/- 3” path training tolerance
Minimum Aisle Width with no Hazard Zones and +/- 3” path training tolerance 8’ 2”
Path Plus Training Tolerance
Rear Axle 20”
Load Width
9”
40”
20”
Appendix A: Laser Training Tool
9”
6’ 10”
Hazard Zone Hazard Zone
Side Alignment Laser Beam = Stop Field + 23” from bumper
Side Alignment Laser Beam = Stop Field + 23” from bumper 31”
23”
23”
Side Alignment Laser Beam = Hazard Zone + 31” from bumper
53”
Front Alignment Laser Beam = 53” from bumper
31” Side Alignment Laser Beam = Hazard Zone + 31” from bumper
Bumper
Stop Field + 9”
NOTE: If the load is wider than 40”, the Side Alignment Laser for the hazard zone should be set to: 29" + 1/2 max load width - 18" (1/2 width of truck).
