Route Management Manual Nodal Maps Figure 59. Detail View of Nodal Map Section
Figure 59 is an expanded view of a section of the nodal map. The numbers within the circles represent the stations. The lines with arrows show the paths or connections that exist between stations, with the arrow showing direction of travel. Each discrete path has a unique ID number. This ID number is useful when trying to edit or delete segments which have been previously trained on the Raymond Courier (see “Retraining Route Segments” on page 85). The ID number is followed by the length of the path and the date that the path was trained. The date is followed by “0.00m Station Teach Composite”, which indicates the beginning of the section.
96
1134254B, Revised: 30 Sep 2016
