In-Vehicle Service Procedures How to Remove the Oil Seal Mechanical/Magnetic Speedometer Special Instructions Prior to replacing the seal, carefully inspect the transmission to make sure the oil leakage is coming from the seal. Pay particular attention to the gasketed surfaces of the rear bearing cover, rear countershaft bearing covers, and shift bar housing. For additional Information on rear seal service, refer to the “Seal Maintenance Guide” TCSM-0912.
Special Tools •
Output Yoke Puller T1
1. Bushing 2. Rear Bearing Cover Assembly 3. Capscrew 4. Speedometer Drive Gear 5. Oil Seal with Slinger 6. O-Ring 7. Speedometer Spacer Assembly
86
1. Rear Bearing Cover 2. Sensor Retaining Capscrew 3. O-Ring 4. Speedometer Sensor 5. Capscrew 6. Oil Seal 7. Slinger 8. O-Ring 9. Speedometer Spacer Assembly 10. Slinger
