In-Vehicle Service Procedures How to Install the Detent Spring Special Instructions None
Special Tools •
Torque Wrench 50 lb. ft. Capacity
Procedure -
Detent Spring
Place the detent spring(s) and detent plunger in the shift block.
Optional Spring Design Detent Plunger Capscrew Shift Block
2.
Place the shift block on the shift shaft using the following procedure. a.
Tilt the shift block so the plunger faces slightly upward.
b.
Place the plunger in the center of the detent notch, and press the detent plunger in to compress the detent springs.
c.
2
While the springs are compressed, roll the shift block into place on the shift shaft. If the shift shaft has been moved or otherwise disturbed, it may be necessary to slide the shift shaft fore or aft to properly install the shift block.
3.
Install the socket head capscrew to secure the shift block. Apply Thread Sealant/Adhesive and Torque the screw to 4045 lb. ft. (54-61 N•m)
4.
Install the shift lever or remote shift control according to the “Shift Lever/ Remote Shift Control Installation” instructions in this section.
3
77
