Transmission Overhaul Procedures-Bench Service
Special Instructions To aid in reassembling the auxiliary section, use a fixture that will hold the countershafts in the proper positions. The dimensions of the fixture are shown in the illustration. The fixture is constructed from a 2”x12”x24” piece of wood.
Special Tools •
Countershaft Retaining Straps T3 24" 3" 12" 11.67" 2"
Procedure 1.
For timing purposes, identify and mark with toolmaker’s dye the two teeth on each countershaft that are identified with an “0”.
1
2.
Place the countershafts in the fixture (or on a clean, flat surface if you don’t have a fixture) with the marked teeth turned to the middle of the fixture.
3.
Position a 2” high spacer, such as a socket, between the countershafts. (If a fixture is not used, a 3” spacer is required.)
2
3
183
Transmission Overhaul Procedures-Bench Service
How to Assemble the Auxiliary Section
