Transmission Overhaul Procedures-Bench Service
Verify that the three magnetic discs are firmly attached to the bottom of the main case. If they are not firmly attached, apply 3M scotch grip or equivalent adhesive to the bottom of the discs and attach them to the main case. If necessary, replace any damaged or worn clutch housing or rear support studs. Apply Eaton®Fuller® thread sealant #71205 or equivalent to any replacement studs before installing them. CAUTION
Confirm that the rear support stud or capscrew does not protrude past the case housing into the transmission. If it protrudes, it could contact the range yoke and disrupt shifting between low and high range.
155
Transmission Overhaul Procedures-Bench Service
How to Prepare the Main Case for Reassembly
