Disassembly How to Install the Input Shaft Assembly (without main case disassembly) Special Instructions None
Special Tools •
See Tool Information (see Table 6)
•
Item T12: Input bearing driver
•
Toolmaker’s dye
Procedure 1.
If necessary, install the bushing in the back of the input shaft.
2.
From the front, engage the input shaft spline teeth into the main drive gear. Note: The current design input shaft spline teeth have noticeable clearance to the main drive gear internal spline teeth. This is normal.
120
3.
Install the snap ring in the main drive gear inside groove.
4.
With the bearing external snap ring to the outside, position the bearing on the input shaft.
