Electrical systems – 5000 Functional description Order number 232370-040
Date 2006-04-10
Valid from serial number 931876-
T-code 787, 788
• Start the truck by pressing the green button and then, within 5 seconds, holding a smart card or ID key close to the scanner on the ID unit. (If the service key is connected, you need only press the green button.) The green LED lights up if login was approved, and the red LED lights up if an invalid smart card/ID key has been used. (Smart cards/ID keys are preprogrammed with a standardised start code.) • Switch off the truck by pressing the red button. The red LED lights up.
Settings Up to 16 types of truck and 14 departments can be used with the system. A smart card/ID key can be programmed for several departments and types of truck, depending on what the driver is authorised to use. A smart card/ID key can also be used to program the ID unit if the type of card is changed (see table below). The truck then detects the department and type of truck selected on the smart card/ID key. When the ID unit is programmed, a red LED lights up for 0.7-0.8 seconds.
Table 13: Settings ID unit Truck
Description
Default setting
Department
Up to 14 departments in any combination (1-14)
All
Type of truck
Up to 16 types of truck in any combination (1-16)
All
Smart card/ID key
Description
Default setting
Department
Up to 14 departments in any combination (1-14)
14
Type of truck
Up to 16 types of truck in any combination (1-16)
16
Type of card
Driver card (1) or programming card (3)
1
Driver profile
Profile for different driver parameters (0-9)
0
Driver ID
-
-
A programming unit from Davis Derby (see image below) is required in order to be able to program a smart card/ID key. The unit is connected to a normal PC.
