Electrical systems – 5000 Functional description T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
10.4.5 TLS - Truck log system (optional) General The truck log system, which is CAN based, is either an integrated system (SD16) or a freestanding supplementary system (S16). A collision sensor can also be connected. The TLS communicates wirelessly with a base station (RG3) once the truck is within range. The base station then receives information on what the truck has done since they last communicated with one another.
PC
Built-in system
A2 Electronic card
RG3
TLS SD16 CAN bus
CAN bus
Add-on system
Shock sensor
A1 Traction controller
TLS S16
Shock sensor
I/O-unit
Registration To register the truck with the base station, follow the instructions below: • Position the truck close to the base station. • Press and hold the green button for approx. 5-10 seconds until three LEDs on the base station start flashing at the same time. The base station can now communicate with the truck whenever it is within range.
Logging in/out SD16 Logging in and out is performed as usual via the keyboard on the handle (or by using an ID unit). The difference is that communication passes through the TLS, which makes all the decisions.
Logging in/out S16 Logging in and out is performed using the keyboard on the TLS. 10- 28
Service Manual
7LOP10CW, 7LOP10CF
© TIEE SARL
