Electromagnetic brake – 3370 Included components T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
7.1 Included components Pos.
Name
Notes
1
Magnet housing
2
Screw
3
Pressure plate
4
Sleeve
5
Shims for air gap adjustment
1 pc. = 0.5 mm 5 pcs. = 0.13 mm in each position
6
Friction plate, brake disc
Nom. thickness: 9.7 mm Min. thickness: 7.7 mm
7
O-ring
8
Hub
9
Mounting plate
10
Screw
3 pcs.
11
Spring
8 pcs.
12
Cable with connector
13
Screw for manual release
3 pcs.
Not included M6
7.2 Disassembly • Loosen the screws (10). • Lift out the brake assembly from the motor axle. • Place the brake assembly on a clean surface. • Gradually unscrew the adjusting screws (2) in order to release the spring tension evenly and little by little.
7.2.1 Inspection Inspect all parts for damage and/or wear. • Be sure to especially examine the brake disc (6) and the wear surface on the pressure plate (3). • Inspect the springs (11) and spacers (4,5) for damage. • Inspect the hub splines (8) and the friction plate splines (6) for damage. • Inspect the magnet plate (1) and pressure plate (3) for swelling/deformations and other damage.
