Driving unit/gear – 2550 Replacing the drive axle jointing ring Order number 232370-040
Date 2006-04-10
Valid from serial number 931876-
T-code 787, 788
6.3.2 Assembly Assembly of the gear unit after replacement of the drive axle jointing ring is done in reverse. Pay special attention to the following during assembly: • Fill the jointing ring with grease after setting it on the drive axle. • Ensure that only undamaged spacing washers of equal total thickness as the original spacers are set on the drive axle. • Press on the bearing on the drive axle, making sure not to damage the bearing spacing washers. • During assembly of the drive axle with attached bearing, spacing washers and jointing ring, make sure the placement of the axle wedges coincide with the crown wheel wedges and that the bearing and jointing ring are properly positioned on the axle prior to pressing the axle into the final position. • Place the spacer ring on the drive axle end and then screw on the axle nut. Be sure to always use a new nut. Tighten the axle nut to a torque of 400 Nm, and lock it with one centre punch in the middle. Lubricate the drive axle nut prior to setting it on the axle. • Replace the O-ring before mounting the lower cover. Make sure it is not damaged. Fit the cover and tighten the bolts to a torque of 25 Nm. Lubricate the bolts prior to mounting. Fill with oil according to the oil filling instructions. Fit the drive wheel and tighten the wheel nut to a torque of 90 Nm. Lubricate the wheel nut prior to mounting.
