Driving unit/gear – 2550 Included components T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
6.1 Included components Pos. Name
6- 2
Notes
1
Motor gear wheel
2
Locking nut
3
Primary gear wheel
4
Tapered roller bearing
5
Shim
6
Shim
7
Tapered roller bearing
8
Tapered roller bearing
9
Locking nut
10
Cover
11
Screw
12
Shim
13
Pinion/crown wheel
14
Drive axle
15
Wheel bolt
Tightening torque 90 Nm Lock using Loctite 270
16
Jointing ring
Fill the jointing ring with grease Seal using Loctite 574
17
Tapered roller bearing
Service Manual
Tightening torque 130 Nm Centre punch to lock
Tightening torque 400 Nm Centre punch to lock
Tightening torque 25 Nm Lock using Loctite 242
Gear play 0.09-0.15 mm. Pretighten the bearing by 2-5/100. The punched measure in the pinion should be adjusted using shims.
7LOP10CW, 7LOP10CF
