Fork carriage – 7420 Dismounting of the mast carriage. Order number 232370-040
Date 2006-04-10
Valid from serial number 931876-
T-code 787, 788
13.2 Dismounting of the mast carriage. • Dismount security split pin position 11 and both chain bolt nuts postion 12. • Dismount washer postions 13. • Remove the complete chain position 14. • Remove the end plates on top of both mast beams. Take the mastcarriage out of the mast at the upper side by using a crane. CAUTION! Take care of save load handling.
14
15
16
17
13 12 11
Mounting is done in reverse.
13.3 Adjusting the play • Adjust the play with screw (15).
13.4 Roller replacement • See also earlier drawing. • Remove the locking ring position (16) and remove the roller (17). Assembly is done in reverse.
© TIEE SARL
Service Manual
7LOP10CW, 7LOP10CF
13- 3
