Maintenance Safety rules during maintenance work T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
• The truck is equiped with a fan for cooling the electronic system. This fan keeps running as long as the main contactor (K10) is activated. Touching the turning fan can injure fingers, hand. • Use paper or a thick paper board to inspect possible hydraulic oil leaks. Do NOT use your hand. • Keep in mind that the transmission oil and hydraulic system oil may be burning hot. WARNING! Risk of burn injuries. Hot transmission and hydraulic oil. Allow the truck to cool down prior to replacing the oil.
• Use only new and clean oil when refilling the hydraulic oil system. WARNING! Risk of damaging the hydraulic system. If the oil is contaminated, the hydraulic system components will be damaged. Always use new and clean oil in the hydraulic system.
• Store and transport replaced oil in accordance with local regulations. • Do not flush solvents, etc. used for cleaning into drains that are not specifically suited for this. Follow local regulations with regards to destruction of oil, solvents, etc. • Disconnect the battery prior to performing welding work on the truck. NOTE! The battery could become damaged. When using an electric welding system, the welding current could reach the battery. Be sure to first disconnect the battery.
• Prior to welding or grinding on painted surfaces, be sure to scrape off the paint at least 100 mm around the welding/grinding site using blasting or a paint remover. CAUTION! Unhealthy gasses. Paint, which is heated, generates unhealthy gasses. Remove the paint 100 mm around the working place.
3- 2
Service Manual
7LOP10CW, 7LOP10CF
© TIEE SARL
