Hydraulic system – 6000 7LOP10CF T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
Symbol list Pos. no.
Description
Function
Notes
1
Lift cylinder
Lifts the cabin
Hose rupture valve
2
Lift cylinder
Lifts the initial forks
Hose rupture valve
3
Flow regulating valve
4
Pressure limiting valve
5
Non-return valve
6
Filter
M3
Motor
P
Pump
B10 + B11
Pressure sensor
T
Tank
Y10
Valve
Cabin / Fork lowering valve
Y45
Valve
Gentle-closing electromagnetic valve for the cabin
Y69
Valve
Gentle-closing electromagnetic valve for the initial
Pump motor
Measures the load
Analogue signal
11.2.3 Description Cabin lifting When the cabin lifting control is actuated, the pump contactor closes and the pump motor starts operating. At the same time, the Y45 valve opens and oils flows through the non-return valve and Y45 to the lift cylinder. If the lifting movement is interrupted, Y45 closes gently.
Cabin lowering When the cabin lowering control is actuated, the electromagnetic valves Y10 and Y45 open completely to allow the oil in the pressure lines to flow back into the oil reservoir. If the lowering movement is interrupted, first Y45 closes slowly and then Y10 closes. To ensure Y45 is completely closed before Y10 closes, Y10 receives a retarded holding voltage from the truck's logic card. The lowering speed cannot be adjusted, and is instead determined by the brake valve for the lowering action in the hydraulic unit valve plate.
11- 6
Service Manual
7LOP10CW, 7LOP10CF
