Hydraulic system – 6000 7LOP10CW T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
11.1.2 Hydraulic drawing and symbol list n
1
4 3
2 5
Symbol list Pos. no.
Description
Function
Notes
1
Lift cylinder
Lifts the cabin
Hose rupture valve
2
Flow regulating valve
10 l / min
3
Pressure limiting valve
max 200 bar
4
Non-return valve
5
Filter
M3
Motor
P
Pump
B10
Pressure sensor
T
Tank
Y10
Valve
Cabin lowering valve
Y45
Valve
Cabin lift/lowering soft closing valve
11- 2
Pump motor
Measures the load
Service Manual
7LOP10CW, 7LOP10CF
Analogue signal
© TIEE SARL
