Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
16 - 0 - 1
Date 2006-04-10
Order number 232370-040
Parameter no. (range 16-19) Argument: #0 holds option designator (displayed for 2 s only) Argument value (range 0 - 63) 0= no base option is activated for this parameter 1 to 6 = Base option no. See See separate tables)
OPTION ASSIGNATION
16 - 1- 1
Argument: #1, #2, #3 & #4 hold configurable values for the option Argument value (range depends on argument) Value depends on option and argument selected See separate table OPTION CONFIGURATION
Fig. 8 Configurable option layout
Setting Configurable options To activate a configurable option the base option must first be assigned to one of the parameters #16 to #19. This is achieved by setting argument #0 to the base option number. Once it is assigned, the option’s arguments must be configured. This is achieved by setting a value for arguments #1, #2, #3 and #4. •
Ensure the truck is in parameter mode.
Parameters symbol lights. •
Select parameter #16, #17, #18 or #19 using [L1].
Argument #0 will be displayed After 1 second the argument’s value will be displayed. A value of “0” indicates no option is assigned to this parameter, in which case continued operation of the speed control L1 will display the next parameter. •
Press horn button S18.
Parameter symbol flashes.
10- 52
.
•
Set argument #0 value by repeatedly operating speed control L1 up or down. Refer to base option list Table 21:
•
Press horn button S18 once to confirm the new setting.
Service Manual
7LOP10CW, 7LOP10CF
