Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
Table 20: Standard PIN code assignment with extended keypad Operator profile
0
1
2
3
4
5
6
7
8
9
Block 0
0000
0001
0002
0003
0000
0000
0000
0000
0000
0000
Block 1
5421
7901
1437
3731
1049
9439
7265
1322
2869
1574
Block 2
1787
4854
2907
9175
5799
1490
3031
7392
5622
5023
Block 3
4659
3174
1026
3815
6703
1179
5152
7514
5668
3215
Block 4
9197
7110
5477
3846
9491
5918
8222
6923
8139
7025
Block 5
2549
6276
9879
9658
1690
4042
5201
9807
4332
9715
Block 6
7474
4142
8620
3754
8432
8788
7430
1948
2595
8527
Block 7
1930
1482
7135
2395
7365
7092
4611
2831
4185
6067
Block 8
2876
4731
1022
5377
3257
7334
9009
7881
8843
7436
Block 9
3242
3162
5878
2828
1910
6907
2136
5730
2957
7691
No.
10.5.9 Configurable “Option” parameters WARNING! The information in this section is not intended as a programming reference and is included solely to allow the reader to gain a thorough understanding of parameter setting/checking. Do not attempt to make any adjustments to these parameters unless you have sufficient knowledge of the truck’s options/modified functions. This manual only covers the truck’s standard equipment. Specially modified trucks may require that you have access to special service information. Improper adjustment of the option service parameters may compromise safe operation and/or result in a malfunction.
General Parameters #16 to #19 are reserved in the truck’s control system for extra truck options and/or special product modifications. The parameters configure and control the behavior of the Spider expansion unit (SEU) which must be fitted in the truck. See “10.4.2 Spider expansion unit (SEU)” on page 25. This method of implementation allows the standard software program to be used without the need for a specialised software. Normally, these parameters are configured by the manufacturer when the truck is modified or customized. It is advisable to upload the parameter settings from trucks which are modified. In the event the main control card[A2] is changed, the original parameter settings can then be transferred to the new card thus ensuring the special option functions correctly. 10- 50
