Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
Extended keypad - General The truck can be programmed with a maximum of 10 operator profiles. The extended keypad then enables a maximum of 10 PIN codes to be assigned to each operator profile. This makes it possible to handle up to 100 different PIN codes. NOTE! If the extended keypad is activated, handling of standard PIN codes, that are normally accessible via parameter #10, is ignored.
Extended keypad - Programming A group of PIN codes can be made accessible by defining them as a block. Block no. 0 is activated in the default setting. This means that 3 different operator profiles can be accessed from the very start. Activation of other blocks will make all the PIN codes for that block accessible (see Table 20:). If all 10 blocks have been activated, then 10 PIN codes will be accessible for the operator profile. The truck software stores the standard PIN code set according to Table 20: NOTE! These PIN codes can be adjusted to any value, however, it is advisable to avoid identical PIN codes in different operator profiles.
10- 48
Service Manual
7LOP10CW, 7LOP10CF
© TIEE SARL
