Electrical systems – 5000 Parameters & adjustments Order number 232370-040
Date 2006-04-10
Valid from serial number 931876-
T-code 787, 788
# 37 - Steering offset This parameter can be used to “trim” the actual steering position of the drive wheel in relation to the position of the steering tiller. It should only be adjusted after having performed a steering calibration (parameter #36). A situation which may require this parameter to be adjusted, is if the truck tends to drift away from a straight ahead course when driving over longer distances. Many factors can contribute to this. It is therefore advisable to make adjustments to this parameter on a trial and error basis. Whenever this parameter is adjusted, it is necessary to restart the truck (disconnect and reconnect battery).
# 39 - Log-in method & operator parameter access This parameter determines which function will be used for log-in and whether or not the operator is allowed to adjust the operator parameter settings. • Value 1 - Key switch installed - Operator parameters accessible (without CAN service key). • Value 2 - Key switch installed - Operator parameters NOT accessible (without CAN service key). • Value 3 - Keypad (standard 10 PIN codes) - Operator parameters accessible (without CAN service key). NOTE: This is the default setting. • Value 4 - Keypad (standard 10 PIN codes) - Operator parameters NOT accessible (without CAN service key). • Value 5 - Extended keypad (100 PIN codes) - Operator parameters accessible (without CAN service key). • Value 6 - Extended keypad (100 PIN codes) - Operator parameters NOT accessible (without CAN service key). • Value 7 - Extended keypad (100 PIN codes) + TLS - Operator parameters accessible (without CAN service key). • Value 8 - Extended keypad (100 PIN codes) + TLS - Operator parameters NOT accessible (without CAN service key). • Value 9 - ID unit - Operator parameters accessible (can be changed without CAN service key). • Value 10 - ID unit - Operator parameters NOT accessible (CAN service key needed). • Value 11 - ID unit + TLS - Operator parameters accessible (can be changed without CAN service key). • Value 12 - ID unit + TLS - Operator parameters NOT accessible (CAN service key needed).
© TIEE SARL
Service Manual
7LOP10CW, 7LOP10CF
10- 47
