Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
# 21 - Battery size Matches the discharge indication to the characteristics of the battery fitted. To adjust the disconnection point of the battery discharge indicator, measure according to: • Acid concentration when fully charged battery. To check quality of battery. Shall be between 1,27-1,29. • When you get lift cut-out (80% discharged of battery capacity) you shall have close to 1,14 not less. The acid concentration can vary depending on battery brand.
Table 18: Battery size parameter Value
Function
Battery (Ah)
1 2 3 4 5 6 7 8 9 10
↑
11
Less discharged
12
*TBA
13
More discharged
14
↓
*TBA
15
*TBA
16
*TBA
17
*TBA
18
*TBA
19 20 * TBA = To be announced
WARNING! Ensure you have set the parameter correctly. The battery may otherwise be irreparably damaged.
10- 44
Service Manual
7LOP10CW, 7LOP10CF
© TIEE SARL
