Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
To enter a new PIN-code: • Operate L1 repeatedly in the forward direction to select parameter #10. After one second, the display will show the PIN-code for this operator. • Repeat the step above until parameter#10 for the next operator is displayed, the display will either show PIN-code for that operator OR “0”(zero). • Repeat the step above until the PIN-code displayed is “0”(zero). • Press horn button S18.
Parameter symbol flashes.
.
• Operate L1 to set the desired value of the new PIN-code.1 • Press horn button S18.
Parameters symbol lights (stops flashing). The new PIN-code has now been entered.
To remove an existing PIN-code: • Operate L1 repeatedly in the forward direction to select parameter #10. After one second, the display will show the PIN-code for this operator. • Repeat the step above until the PIN-code to be removed is displayed. • Press horn button S18.
Parameter symbol flashes.
.
• Operate L1 to set the PIN-code value to “0”(zero). • Press horn button S18.
Parameters symbol lights (stops flashing). The selected PIN-code has now been removed. To check whether a PIN-code will start the truck follow the procedure in 2. Switch on (PIN-code entry) on page 20. Parameter #10 cannot be displayed without the CAN service key. 1.Operating L1 lightly will step the value in increments of 1. Operating L1 fully will step the value in increments of 100 Valid values are 1 to 9999 10- 40
Service Manual
7LOP10CW, 7LOP10CF
