Electrical systems – 5000 Parameters & adjustments Order number 232370-040
Date 2006-04-10
Valid from serial number 931876-
T-code 787, 788
• Hold S18 depressed until “P” is displayed, then release S18. Fig. 6
Parameters symbol lights. Fig. 6
When pressing the speed control L1 forwards repeatedly, the first operator profile will be displayed. Continue to press L1 in the forward direction and the next operator profile will be displayed (operator no. 2), etc. until the last operator (operator no. 10). See Fig. 7 Once the 10 operator profile have been displayed, the truck service parameters will be displayed as L1 is repeatedly pressed in the forward direction.
Operator parameter no. Profile no. Fig. 7
Changing a parameter • Select the required parameter. • Press horn button S18.
Parameter symbol flashes.
.
• Set the parameter value by repeatedly operating speed control L1 up or down • Press horn button S18 once to confirm the new setting.
Parameters symbol lights. (stops flashing).
• Switch off the truck by pressing
on the keypad.
You have now completed a parameter change and the next time you start the truck the new parameter setting will be valid. The truck’s service parameters can be displayed first by operating speed control L1 in the backward direction. This will cause parameter #40 to be displayed and then parameter #39 etc.1 For detailed descriptions and effects of these parameters see the section List of Service parameters on page 38. NOTE! Truck handling. Modifying specific truck parameters will change the driving characteristics of the truck. Do not change any parameters without the necessary know how.
1.Certain parameters numbers displayed are not active in this truck model. © TIEE SARL
Service Manual
7LOP10CW, 7LOP10CF
10- 35
