Electrical systems – 5000 Parameters & adjustments T-code 787, 788
Valid from serial number 931876-
Date 2006-04-10
Order number 232370-040
10.5.3 Adjusting operator parameters without the CAN service key NOTE! Operator parameters can only be set without a CAN key if parameter #39 is set to value “1”, “3”, ”5”, “7”, “9” or “11”. See # 39 - Log-in method & operator parameter access on page 47.
To change the value of a particular operator parameter carry out the following: • Switch on the truck and log in with the appropriate PIN-code. This is important if the truck has more than one set of Operator parameters active . Any changes made will only be in effect when that particular “operator” is logged in. • Select the required parameter. • Press horn button S18.
Parameter symbol flashes.
.
• Set parameter value by repeatedly operating speed control L1 up or down • Press horn button S18 once to confirm the new setting.
Parameters symbol lights. (stops flashing).
• Switch off the truck by pressing
on the keypad.
You have now completed a parameter change and the next time you start the truck the new parameter setting will be valid. For detailed descriptions and effects of these parameters, see the section Description of operator parameters on page 37
10.5.4 Displaying & changing parameters CAN service key connected • Ensure the battery is connected. • Connect a suitable CAN-service key to X41. • Ensure the truck is switched off. Press
on the keypad.
• Press and hold horn button S18 for at least 1 second and then press on the keypad.
10- 34
Service Manual
7LOP10CW, 7LOP10CF
© TIEE SARL
