Shift Bar Housing How to Disassemble the New Forward Shift Bar Housing (w/Super 10 on cover) Special Instructions The shift bar housing must be removed from the transmission. During disassembly, lay all parts on a clean bench in order of removal to facilitate assembly. Shift bars not being removed must be kept in the neutral position or the interlocking parts lock the bars. Start with the bottom shift bar. Cut the lockwire and remove the lockscrews from each bar just before their removal.
Special Tools •
Typical Service Tools
Procedure -
83
1.
If the two (2) sets of tension springs and balls from housing bores have not been removed, place the shift bar housing on its side to remove them. Check the condition of the alignment pin, replace if necessary.
2.
If installed, remove the oil trough retaining capscrews and oil trough.
3.
With the housing rear to the right, lay the assembly on a flat surface.
4.
While removing the bottom yoke bar, remove the shift yoke.
