Shift Bar Housing How to Assemble the Standard Shift Bar Housing (w/Super 10 on cover) Special Instructions Inspect shift blocks and shift yokes for wear. Apply Eaton sealant #71208 or equivalent to the shift bar housing plugs which are used to plug oil cooler provision holes. The sealant should be applied so that at least 5 complete threads are covered. Apply Eaton lockwire #1819 or equivalent to all shift bar housing assembly set screws in both blocks and yokes. The wire should anchor the capscrew at least 2 complete 360° turns. The lockwire ends should be trimmed and bent out of the way of any part interference. Keep yoke bars in neutral while assembling.
Special Tools •
Typical Service Tools
Procedure -
2.
Shift Bar Housing
1.
Assemble the 1st & reverse shift yoke assembly: a.
Install the plunger in the 1st & reverse shift yoke bore, plunger shank to the outside.
b.
Install the spring into the bore over the plunger shank.
c.
Position the washer over the plunger shank.
d.
Install the snap ring.
Assemble the 3rd speed block assembly: a.
Install the plunger in the 3rd shift block bore, plunger shank to the outside.
b.
Install the spring into the bore over the plunger shank.
c.
Install the plug and tighten to compress the spring.
d.
After plug bottoms out, back the plug out 1-11/2 turns.
e.
Complete the block assembly process by staking the plug through the small hole in block.
