Shift Bar Housing How to Disassemble the Standard Shift Bar Housing Special Instructions The shift bar housing must be removed from the transmission. During disassembly, lay all parts on a clean bench in order of removal to facilitate assembly. Shift bars not being removed must be kept in the neutral position or the interlocking parts lock the bars. Start with the bottom shift bar. Cut the lockwire and remove the lockscrews from each bar just before their removal.
Special Tools •
Typical Service Tools
Procedure -
65
1.
If the two (2) sets of tension springs and balls from housing bores and the anti-rotating pin have not been removed, place the shift bar housing on its side to remove them.
2.
With the housing rear to the right, lay the assembly on a flat surface. If installed, remove the oil trough retaining capscrews and oil trough.
3.
While removing the bottom yoke bar, remove the shift yoke.
