Changing The Input Shaft How to Install the Input Shaft Without Disassembling the Transmission Special Instructions Check the bushing in the input shaft pocket, replace if worn.
Special Tools •
Typical Service Tools
•
Input Shaft Bearing Driver
Procedure -
57
1.
Install the new input shaft into main drive gear splines.
2.
Position the input shaft just far enough into the gear to expose the drive gear I.D. snap ring groove.
3.
Install the drive gear I.D. snap ring.
4.
Install the drive gear spacer on the input shaft.
5.
With the external snap ring to the outside, slide the drive gear bearing on the input shaft and position into the case bore.
