Clutch Housing How to Install the Clutch Housing Special Instructions Installation of the clutch housing is done in the horizontal position.
Special Tools •
Typical Service Tools
Procedure Position a new gasket on the housing mounting surface.
2.
Install the clutch housing on the front box, pilot it on the six studs and drive gear bearing cover.
3.
Install the nuts with washers or lockwashers on the studs, tighten to 35 lb-ft (47 N.m) + 90° CW rotation or 175 lb-ft (237 N.m) of torque.
4.
Install the capscrews with lockwashers, tighten to 115 lb-ft (156 N.m) of torque.
External Parts
1.
Final Check •
Make sure the capscrews are properly torqued.
54
