Auxiliary Section How to Remove the Auxiliary Section Without Tapered Bearings Special Instructions There can be different capscrew lengths, note their location. Auxiliary sections can be removed either with the transmission in the horizontal position or the vertical position.
Special Tools •
Typical Service Tools
•
An auxiliary section hanger bracket for horizontal removal
•
A steel bar longer than the width of the output yoke for vertical removal
•
A hoist with a lifting chain
Procedure - To remove the auxiliary section in the horizontal position.
41
1.
From the auxiliary section housing, remove the retaining capscrews that attach the front section to the auxiliary section.
2.
Insert the two (2) longest capscrews in the housing flange tapped holes. Tighten evenly to move the auxiliary section away from the front box. Go far enough to break the gasket seal.
